Model |
IPC-H3D470 |
|
Form Factor |
3U |
|
Configuration |
CPU:I7-10700 4.8GHZ, 8 cores and 16 threads. Memory: 16GB DDR4 2666 |
|
GPIO |
8 x GPI, 8 x GPO, (shared with LPT header) |
|
Ethernet |
2 x LAN: Intel® I219V with 10/100/1000 Mbps,support AMT/vPro |
|
Ports |
Front:2xUSB2.0; Rear:2xUSB2.0; 4xUSB3.0; 4xfast 232/422/485 serial ports; 1xVGA, 1xHDMI, 1xDVI 1x DP, High Definition Audio, Line-In/ Line-Out/ Mic-In |
|
TPM |
On board |
|
PSU |
850W server ATX power supply |
|
Cooling Fans |
2x Hot-Swappable 8038mm(option 1x 8038mm) |
|
Fans Failure Alarm |
Yes |
|
PCIE |
1 x PCI-E 3.0 x16 slots,1 x PCI-E 3.0 x8 slots,3 x PCI-E 3.0 x4 slots; 2 x PCI |
|
HDD |
1T SATA 7200 Seagate hard drive * 2 |
|
Graphics card Support |
Support full size NVIDIA GeForce RTX 3090(backward compatible) |
|
Slide Rail |
Included |
|
Power input |
100-230V, 50/60Hz |
|
Indicators |
1x Power Status, 1x HDD Activity, 2x LAN Activity, 1x Failure |
|
Front Buttons |
Power On/Off, System Reset |
|
Metal Thickness |
1mm SGCC |
|
Dimension |
53 x 437.5 x 133cm (D x W x H) |
|
Working temperature |
0ºC ~ 60ºC |
|
Weight(LBS) |
NW:23.14 GW:36 |
|
Certification |
CE/FCC/RoHS |
